N42AC3Z


float


float

Features

  • 1/3-in. 4 MP Progressive CMOS
  • Smart H.264+ and H.264 Dual-stream Encoding
  • 4 MP at 20 fps and 3 MP at 30 fps
  • WDR (120 dB), Day/Night (ICR), 3DNR, AWB, AGC, BLC
  • Multiple Network Monitoring: Web Viewer, CMS (DSS/PSS) and DMSS
  • Micro SD Card Support, up to 128 GB
  • 2.7 mm to 12 mm Varifocal Lens
  • Max. IR LED Length 60 m (197 ft)
  • IP67, PoE

Compression

FOV

Firmware Update Instructions

Firmware Update Download

Body Style with Compatible Accessories

Specifications

Camera
Image Sensor 1/3-in. 4 MP Progressive CMOS
Effective Pixels 2688(H)  x 1520(V)
RAM/ROM 256 MB / 16 MB
Scanning System Progressive
Minimum Illumination Color: 0.1 Lux at F1.4
  0 Lux at F1.4 (IR on)
S/N Ratio More than 50 dB
IR Distance Distance up to 60 m (197 ft)
IR On/Off Control Auto, Manual
IR LEDs Four (4)
Lens
Lens Type Motorized
Mount Type Board-in
Focal Length 2.7 mm to 12 mm
Max. Aperture F1.4
Angle of View Horizontal: 35° to 100°
  Vertical: 20° to 54°
Focus Control Auto
Close Focus Distance 0.3 m
Range
Pan/Tilt Pan: 0° to 360°
  Tilt: 0° to 90°
  Rotation: 0° to 360°
Video
Compression Smart H.264+¹, H.264
Streaming Capability Two (2) Streams
Resolution 4 MP (2688 x 1520), 3 MP (2304 x 1296),
  1080p (1920 x 1080), 1.3 MP (1280 x 960),
  720p (1280 x 720), D1 (704 x 480), CIF (352 x 240)
Frame Rate
Main Stream 4 MP at 20 fps or 3 MP at 30 fps
Sub Stream D1, CIF at 30 fps
Bit Rate Control CBR, VBR
Bit Rate H264: 24 K to 8192 Kbps
Day/Night Auto (ICR), Color, B/W
BLC Mode BLC, HLC, WDR (120 dB)
White Balance Auto, Natural, Street Lamp, Outdoor, Manual
Gain Control Auto, Manual
Noise Reduction 3D DNR
Motion Detection Off, On (4 Zone, Rectangle)
Region of Interest Off, On (4 Zone)
Smart IR Support
Digital Zoom 16x
Flip 0°/90°/180°/270°
Mirror Off, On
Privacy Masking Off, On (4 Area, Rectangle)
Network
Ethernet RJ-45 (10/100 Base-T)
Protocol HTTP, HTTPs, TCP, ARP, RTSP, RTP, UDP, SMTP,FTP,
  DHCP, DNS, DDNS, PPPOE, IPv4/v6, QoS, UPnP, NTP,
  Bonjour, 802.1x, Multicast, ICMP, IGMP
Interoperability ONVIF, PSIA, CGI
Streaming Method Unicast / Multicast
Max. User Access 10 Users / 20 Users
Edge Storage NAS (Network Attached Storage)
  Local PC for instant recording
  Micro SD Card, max. 128 GB
Web Viewer IE, Firefox, Safari
Management Software Smart PSS, DSS
Mobile Operating System IOS, Android
Certifications
Safety UL 60950-1
Electromagnetic Compatibility (EMC) FCC Part 15 Subpart B
Electrical
Power Supply DC12V, PoE (802.3af, Class 0)
Power Consumption < 12.95 W
Environmental
Operating Conditions -30° C to +60° C (-22° F to +140° F),
  Less than 95% RH
Storage Conditions -30° C to +60° C (-22° F to +140° F),
  Less than 95% RH
Ingress Protection  IP67
Construction
Casing Metal
Dimensions 90.40 mm × 90.40 mm × 212.80 mm
  (3.56 in. x 3.56 in. x 8.40 in.)
Net Weight 0.68 kg (1.51 lb)
Gross Weight

0.86 kg (1.90 lb)
