N84BG44

N84BG44
Specifications Quick Start Guide Manual Firmware
N84BG44 IPC HDW4421EM AS.png
Series: Pro
Body: Eyeball
Image Sensor: 1/2.5-in. 8 MP Progressive Scan CMOS
Resolution: 8 MP, 3840(H) x 2160(V)
Angle of View: Horizontal: 87°
Vertical: 48°
Lens Type: Fixed
Focal Length: 4 mm
Min. Illumination: Color: 0.05 lux at F1.6
B/W: 0 lux at F1.6 (IR on)
Day/Night: Auto (ICR), Color, B/W
Max. IR Range: Up to 50.0 m (164.04 ft)
WDR: 120dB
Video Compression: Smart H.265+, H.265, Smart H.264+, H.264
Audio Compression: G.711a, G.711Mu, AAC, G.726
Frame Rate: 4K/8 MP (1 to 15 fps) or 3 MP (1 to 30 fps)
Multi-Streaming: 3 Streams
IVS: Motion, Tripwire, Intrusion,
Scene Change, Abandoned/Missing Object,
Facial Detection
ONVIF: Yes
Audio In: 1 (Built-in Microphone)
Audio Out: 0
Memory Slot: Micro SD Slot, maximum 128 GB
Alarm In: 0
Alarm Out: 0
IP Rating: 67
IK Rating: -
Operating Temp: –30° C to +60° C (–22° F to +140° F)
Less than 95% RH
Power: DC12V, PoE (802.3af, Class 0)
< 5 W
ePoE: No

Features

  • 1/2.5-in. 8 MP Progressive Scan CMOS
  • Smart H.265+ and H.264 Triple-stream Encoding
  • 15 fps @ 4K/8 MP (3840 x 2160) and 30 fps @ 3 MP (2304 x 1296)
  • Smart Detection Supported
  • Digital WDR and Day/Night IR Cut Filter
  • 4 mm Fixed Lens
  • Max. IR LED Length 50 m (164 ft)
  • Built-in Microphone
  • Micro SD Memory, IP67, PoE

Compression

Intelligent Features

Interfaces

WebUI Old SmartPSS DSS Express S
WebUI Old SmartPSS DSS Express S

FOV

Compatible Accessories

Compatible Accessories
Accessories Combo 1 PFA139PFA139
Accessories Combo 2 PFA139PFA139 PFA150PFA150
Accessories Combo 3 PFB204WPFB204W
Accessories Combo 4 PFB204WPFB204W PFA152PFA152
Accessories Combo 5 PFA121PFA121
Accessories Combo 6 PFA121PFA121 PFA151PFA151
Accessories Combo 7 PFA121PFA121 PFA150PFA150

Specifications
