Step by Step Instructions

1. From the home screen select Device

L26 C26 - Modify PIR Detection Zone - DMSS - 1.jpg

2. Select the device from the list

L26 C26 - Modify PIR Detection Zone - DMSS - 2.jpg

3. Select Floodlight

400px

4. Select PIR Region

400px

5. Tap a Zone to disable/enable

L26 C26 - Modify PIR Detection Zone - DMSS - 5.jpg

6. Use the slide to adjust the range of the Zones

L26 C26 - Modify PIR Detection Zone - DMSS - 6.jpg

7. Press the Save icon in the top right to save settings

L26 C26 - Modify PIR Detection Zone - DMSS - 7.jpg

L26 C26 - Modify PIR Detection Zone - DMSS - 8.jpg
