DHL42

DHL42


Features

  • Industrial level DID LCD panel, suitable for extensive 7*24 continuous works
  • High fidelity digital processing, brilliant and vivid video.
  • 5.8ms fast response time, no picture ghosting
  • Built-in 3D COMB filter and 3D Noise Reduction
  • Abundant interfaces HDMI, DVI, VGA, BNC, support video loop
  • Infrared, RS232 double mode, supporting remote PC control
  • Brightness smart detection, power-saving
  • Using Tamper-proof metal housing, no radiation
  • Professional thermal design to extend equipment lifespan
  • Built-in power, low energy consumption, ultra-quiet
  • Fast stack installation, professional project design, supporting arc-shaped mounting


Specifications

Model DHL42
System
Diagonal 42"(16:9)
Resolution 1920×1080 (FHD)
Backlight LED
Brightness/Luminance (Standard) 700 cd/m2
Contrast 1000:1
Angle of view 178°/178°(vertical/horizontal)
Response time 5.8ms
Signals
Input standard VGA(D-Sub)×1.CVBS(BNC)×2.DVI-D×1.HDMI×1.RS232×1
optional audio×1
Output Standard CVBS(BNC)×2. RS232×1
optional DP×1
General
Consumption (Standard) 65W
Consumption (Standby) ≤1W
Power Supply AC100~240V (+/-10%),50/60 Hz
Gross Weight 17kg
Monitor dimensions 1004.00×598.00×48.20mm
Work Environment Temperature:0ºC~50ºC
Humidity:20%~90%
Accessory
Standard VGA cable, power cable
Optional Pedestal, hanging bracket
