| | ===Specifications=== | | ===Specifications=== |
| − | {{#iDisplay:https://dahuawiki.com/index.php?action=ajax&title=-&rs=SecureFileStore::getFile&f=/c/ca/Datasheet_2MP_30x_Starlight_HDCVI_PTZ_Camera_59230IC_v001_004.pdf|100%|600}} | + | {{#iDisplay:https://dahuawiki.com/images/c/ca/Datasheet_2MP_30x_Starlight_HDCVI_PTZ_Camera_59230IC_v001_004.pdf|100%|600}} |
| | + | |
| | | | |
| − | <!--
| |
| − | ===Specifications===
| |
| − | {| class="wikitable" border="0" width="700" cellspacing="0" cellpadding="0"
| |
| − | |-
| |
| − | | width="188" height="19"|Camera
| |
| − | | width="512"|
| |
| − | |-
| |
| − | | height="19"|Image Sensor
| |
| − | ||1/2.8 in. STARVIS™ CMOS
| |
| − | |-
| |
| − | | height="19"|Effective Pixels
| |
| − | ||1920(H) x 1080(V), 2 MP
| |
| − | |-
| |
| − | | height="19"|Scanning System
| |
| − | ||Progressive
| |
| − | |-
| |
| − | | height="19"|Electronic Shutter Speed
| |
| − | ||1/3 s to 1/300,000 s
| |
| − | |-
| |
| − | | height="19"|Minimum Illumination
| |
| − | ||Color: 0.005 lx at F1.6
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||0 lux at F1.6 with IR on
| |
| − | |-
| |
| − | | height="19"|S/N Ratio
| |
| − | ||More than 55dB
| |
| − | |-
| |
| − | | height="19"|IR Distance
| |
| − | ||Distance up to 150 m (492.13 ft)
| |
| − | |-
| |
| − | | height="19"|IR On/Off Control
| |
| − | ||Auto/Manual
| |
| − | |-
| |
| − | | height="19"|IR LEDs
| |
| − | ||Four (4)
| |
| − | |-
| |
| − | | height="19"|Lens
| |
| − | ||
| |
| − | |-
| |
| − | | height="19"|Focal Length
| |
| − | ||4.5 mm to 135 mm
| |
| − | |-
| |
| − | | height="19"|Maximum Aperture
| |
| − | ||F1.6 to F5.0
| |
| − | |-
| |
| − | | height="19"|Horizontal Angle of View
| |
| − | ||Horizontal: 2.4° to 67.8°
| |
| − | |-
| |
| − | | height="19"|Optical Zoom
| |
| − | ||30x
| |
| − | |-
| |
| − | | height="19"|Focus Control
| |
| − | ||Auto, Manual
| |
| − | |-
| |
| − | | height="19"|Close Focus Distance
| |
| − | ||100 mm to 1000 mm (3.94 in. to 39.37 in.)
| |
| − | |-
| |
| − | | height="22"|DORI Distance<span class="font5"><sup>1</sup></span>
| |
| − | ||
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||Detect (8 ppf): 1862 m (6109 ft)
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||Observe (19 ppf): 744 m (2441 ft)
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||Recognize (38 ppf): 372 m (1220 ft)
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||Identify (76 ppf): 186 m (610 ft)
| |
| − | |-
| |
| − | | height="19"|PTZ
| |
| − | ||
| |
| − | |-
| |
| − | | height="19"|Pan/Tilt Range
| |
| − | ||Pan: 0° to 360° endless
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||Tilt: -15° to 90°
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||Auto Flip 180°
| |
| − | |-
| |
| − | | height="19"|Manual Control Speed
| |
| − | ||Pan: 0.1° to 300° /s;
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||Tilt: 0.1° to 200° /s
| |
| − | |-
| |
| − | | height="19"|Preset Speed
| |
| − | ||Pan: 400° /s
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||Tilt: 300° /s
| |
| − | |-
| |
| − | | height="19"|Presets
| |
| − | | class="xl65"|300
| |
| − | |-
| |
| − | | height="19"|PTZ Mode
| |
| − | ||5 Pattern, 8 Tour, Auto Pan, Auto Scan
| |
| − | |-
| |
| − | | height="19"|Speed Setup
| |
| − | ||Human-oriented Focal Length and Speed Adaptation
| |
| − | |-
| |
| − | | height="19"|Power up Action
| |
| − | ||Auto restore to previous PTZ and lens status after power failure
| |
| − | |-
| |
| − | | height="19"|Idle Motion
| |
| − | ||Activate Preset, Scan, Tour, Pattern if there is no command in the specified period
| |
| − | |-
| |
| − | | height="19"|Protocol
| |
| − | ||DH-SD, Pelco-P/D (Auto recognition)
| |
| − | |-
| |
| − | | height="19"|Video
| |
| − | ||
| |
| − | |-
| |
| − | | height="19"|Resolution
| |
| − | ||1080p (1920 × 1080)
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||720p (1280 × 720)
| |
| − | |-
| |
| − | | height="19"|Frame Rate
| |
| − | ||1080p at 30 fps or 720p at 30/60 fps
| |
| − | |-
| |
| − | | height="58"|Video Output
| |
| − | | class="xl66" width="512"|One (1) Channel, BNC <br />High-definition Video Output (HDCVI, AHD, TVI) or <br />CVBS Standard Definition Video Output (switchable)
| |
| − | |-
| |
| − | | height="22"|Video Transmission<span class="font5"><sup>2</sup></span>
| |
| − | ||
| |
| − | |-
| |
| − | | height="39"|RG-59/U Coax
| |
| − | | class="xl66" width="512"|720p: 500 m (1640.42 ft)<br />1080p: 400 m (1312.34 ft)
| |
| − | |-
| |
| − | | height="39"|RG-6/U Coax
| |
| − | | class="xl66" width="512"|720p: 800 m (2624.67 ft)<br />1080p: 600 m (1968.50 ft)
| |
| − | |-
| |
| − | | height="39"|CAT 6 UTP (balun required)
| |
| − | | class="xl66" width="512"|720p: 380 m (1246.72 ft)<br />1080p: 380 m (1246.72 ft)
| |
| − | |-
| |
| − | | height="19"|Day/Night
| |
| − | ||Auto (ICR), Color, B/W
| |
| − | |-
| |
| − | | height="19"|OSD Menu
| |
| − | ||English, French, German, Italian, Japanese, Polish, Portuguese, Russian, Spanish
| |
| − | |-
| |
| − | | height="19"|Advanced Features
| |
| − | ||BLC, HLC, WDR (120 dB)
| |
| − | |-
| |
| − | | height="19"|Backlight Compensation
| |
| − | ||Auto, ATW, Indoor, Outdoor, Manual
| |
| − | |-
| |
| − | | height="19"|White Balance
| |
| − | ||Auto, Manual
| |
| − | |-
| |
| − | | height="19"|Gain Control
| |
| − | ||Ultra DNR (2D/3D)
| |
| − | |-
| |
| − | | height="19"|Noise Reduction
| |
| − | ||Defog
| |
| − | |-
| |
| − | | height="19"|Digital Zoom
| |
| − | ||16x
| |
| − | |-
| |
| − | | height="19"|Flip
| |
| − | ||180°
| |
| − | |-
| |
| − | | height="19"|Privacy Masking
| |
| − | ||Up to 24 areas
| |
| − | |-
| |
| − | | height="19"|Certifications
| |
| − | ||
| |
| − | |-
| |
| − | | height="19"|CE
| |
| − | ||EN 55032
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||EN 55024
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||EN 50130-4
| |
| − | |-
| |
| − | | height="19"|UL
| |
| − | ||UL60950-1 + CAN/CSA C22.2, No.60950-1
| |
| − | |-
| |
| − | | height="19"|Electromagnetic Compatibility (EMC)
| |
| − | ||FCC Part 15 Subpart B
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||ANSI C63.4-2014
| |
| − | |-
| |
| − | | height="19"|Interface
| |
| − | ||
| |
| − | |-
| |
| − | | height="19"|Video Output
| |
| − | ||Output: One (1) BNC
| |
| − | |-
| |
| − | | height="19"|Audio Input
| |
| − | ||Input: One (1) Channel
| |
| − | |-
| |
| − | | height="19"|RS485
| |
| − | ||One (1) Port
| |
| − | |-
| |
| − | | height="19"|Alarm
| |
| − | ||Input: Two (2) Channels
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||Output: One (1) Channel
| |
| − | |-
| |
| − | | height="19"|Electrical
| |
| − | ||
| |
| − | |-
| |
| − | | height="19"|Power Supply
| |
| − | ||24 VAC, 3 A (±10%)
| |
| − | |-
| |
| − | | height="19"|Power Consumption
| |
| − | ||13 W, 23 W with IR on
| |
| − | |-
| |
| − | | height="19"|Environmental
| |
| − | ||
| |
| − | |-
| |
| − | | height="19"|Operating Conditions
| |
| − | ||-40° C to 60° C (-40° F to +140° F),
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||with built-in heater, Less than 90% RH
| |
| − | |-
| |
| − | | height="19"|Ingress Protection
| |
| − | ||IP66
| |
| − | |-
| |
| − | | height="19"|Construction
| |
| − | ||
| |
| − | |-
| |
| − | | height="19"|Casing
| |
| − | ||Metal
| |
| − | |-
| |
| − | | height="19"|Dimensions
| |
| − | ||186.0 mm x 309.0 mm (7.32 in. x 12.17 in.)
| |
| − | |-
| |
| − | | height="19"|Net Weight
| |
| − | ||3.50 kg (7.72 lb)
| |
| − | |-
| |
| − | | height="19"|Gross Weight
| |
| − | ||6.80 kg (14.99 lb)
| |
| − | |-
| |
| − | | height="19"|
| |
| − | ||
| |
| − | |-
| |
| − | | class="xl67" colspan="2" width="700" height="125"|1. The DORI distance is a measure of the general proximity for a specific classification to help pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specifications and lab test results according to EN 62676-4, the standard that defines the criteria for the Detect, Observe, Recognize and Identify classifications.<br />2. Transmission distance results verified by real-scene testing in Dahua's test laboratory. Actual transmission distances may vary due to external influences, cable quality, and wiring structures.
| |
| − | |}
| |
| − | -->
| |
| | | | |
| | [[Category:Model Specific Pages]] | | [[Category:Model Specific Pages]] |
- To avoid any issues with performance do not use baluns when connecting a PTZ camera.
