  • Embedded Processor
  • Dual-stream Recording
  • Smart H.264+ Video Compression
  • 16 HDCVI/AHD/TVI/CVBS Channels
  • Maximum 16 + 8 IP Camera Channels, each channel up to 5 MP on IP cameras only
  • Maximum 96 Mbps Incoming Bandwidth
  • Smart Search and Intelligent Video System (IVS)



Firmware Update Download


Firmware Version V3.218.0000001.2.R.170808
Smart IPC (Front-end Intelligent) Yes
Smart 2.0 Yes
Back-end Intelligent
IVS 1-ch
Face Detection 1-ch
People Counting N/A
Smart Tracking N/A
HDCVI 4MP Fisheye preview N/A
Fisheye dewarp
Local N/A
Web N/A
SmartPSS N/A
Smart264 Encode Yes
Smart265 Encode N/A
Smart265 Decode N/A


Main Processor Embedded Processor
Operating System Embedded Linux
Interface Two (2) HDMI ports
  One (1) VGA port
  One (1) 1 TV port
Resolution 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Multi-screen Display 1/4/8/9/16/25
On-screen Display Camera Title, Time, Video Loss, Camera Lock, Motion Detection, Recording
Video Detection and Alarm
Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 × 18),
Video Loss, Tampering and Diagnosis
Alarm Input 16 Channels
Relay Output Six (6) Channels
Playback and Backup
Playback 1/4/9/16
Search Mode Time /Date, Alarm, MD and Exact Search
  (accurate to 1 second), Smart Search
Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode USB Device and Network
Internal HDD 4 SATA Ports, up to 8 TB capacity for each disk
HDD Mode Single
eSATA One (1)
Auxiliary Interface
USB One (1) USB 2.0 port
  Two (2) USB 3.0 ports
RS232 One (1) Port for PC Communication and Keyboard
RS485 One (1) Port for PTZ Control
Audio and Video
HDCVI Camera Input 16 Channels
IP Camera Input 16 + 8 Channels, each channel up to 5 MP
Audio Input: Four (4) Channels
  Output: One (1) Channel
Two-way Talk Input: One (1) BNC Microphone Connector
  Output: One (1) BNC Microphone Connector
Compression Smart H.264+, H.264, MJPEG
Resolution 1080p, 720p, 960H, D1, HD1, BCIF, CIF, QCIF
Record Rate
Main Stream 1080p, 720p, 960H, D1, HD1, BCIF, CIF, QCIF at 30 fps
Sub Stream D1, CIF, QCIF at 15 fps
Bit Rate 1 Kbps to 6144 Kbps per Channel
Record Mode Manual, Schedule (Regular, Continuous), MD (Video Detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval 1 to 60 minutes (default: 60 minutes),
  Pre-record: 1 to 30 s,
  Post-record: 10 to 300 s
Interface One (1) RJ-45 Port (1000 Mbps )
Network Function HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P, IP Search (Supports Dahua IP cameras, DVRs, NVS)
Maximum User Access 128 Users
Mobile Operating System IOS, Android
Interoperability ONVIF 2.4.1, CGI Conformant
Power Supply 100 to 240 VAC, 50/60 Hz
Power Consumption < 30 W, without HDD
Operating Conditions -10° C to +55° C (+14° F to +131° F), 86 to 106 kpa
Storage Conditions 0° C to +50° C (+32° F to +122° F), 0 to 90% RH
Dimensions 1.5U, 440.0 mm x 416.70 mm x 76.0 mm
(17.30 in. x 16.40 in. x 3.0 in.)
Net Weight 6.0 kg (13.23 lb), without HDD
Gross Weight 7.0 kg (15.43 lb)
Installation Desktop or Rack-mount Installation
Safety Complies with UL Standard
Electromagnetic Compatibility (EMC) FCC: VFHKEM1612001679IT
  CE: SHEM161100752701ITC
IVS triggers an alarm and takes a defined action for the following events:
Standard Features Tampering with the camera.
  Error writing to an onboard Micro SD card.
  Error sending or receiving data over the network.
  Unauthorized access to the camera.
Premium Features
Motion An object moves through any part of the scene.
Tripwire A target crosses a user-defined line.
Intrusion A target enters or exits a defined perimeter.
Scene Change A person or object moves the camera to change the scene or covers the camera to obscure the scene.
Abandoned/Missing Object A target leaves an object in designated area, or a target removes an object from the same designated area.
Advanced Features
Facial Detection Detects and captures a snapshot of human face in a defined area within a scene.
