USA/IPCamera/PTZ/Lite/22204TNI
22204TNI
| Specifications | Quick Start Guide | Manual | Firmware |
|---|---|---|---|
| Coming Soon |
Build Date: 7-5-2021
|
| Series: | Lite |
| Body: | PTZ |
| Image Sensor: | 1/2.8-in. STARVIS™ CMOS Sensor |
| Resolution: | 2 MP, 1920(H) x 1080(V) |
| Angle of View: | Horizontal: 30° to 112.5° |
| Lens Type: | Varifocal |
| Focal Length: | 2.7 mm to 11 mm |
| Optical Zoom: | 4x |
| Min. Illumination: | Color: 0.005 lux at F1.6 B/W: 0.0005 lux at F1.6 |
| Day/Night: | Auto (ICR), Color, B/W |
| Max. IR Range: | - |
| WDR: | 120dB |
| Video Compression: | Smart H.265+, H.265, Smart H.264+, H.264 |
| Audio Compression: | - |
| Frame Rate: | 1080p, 720p, or D1 at 30 fps |
| Multi-Streaming: | 3 Streams |
| Pan/Tilt Range: | Pan: 0° to 355° Tilt: 0° to 90° |
| Preset Speed: | 300 Presets Pan: 100° /s Tilt: 60° /s |
| IVS: | Motion, Tripwire, Intrusion, Scene Change, Abandoned/Missing Object |
| ONVIF: | Yes |
| Audio In: | - |
| Audio Out: | - |
| Memory Slot: | Micro SD Slot, maximum 128 GB |
| Alarm In: | - |
| Alarm Out: | - |
| IP Rating: | 66 |
| IK Rating: | 10 |
| Operating Temp: | –30° C to +60° C (–22° F to +140° F), Less than 95% RH |
| Power: | 12 VDC, 1.5 A; PoE (802.3af Class 0) < 10 W |
| ePoE: | No |
Features
- 1/2.8-in. 2MP STARVIS™ CMOS Sensor
- Powerful 4x Optical Zoom
- Starlight Technology for Ultra-low Light Sensitivity
- Triple-stream Encoding
- True Wide Dynamic Range (120 dB) and True Day/Night (ICR)
- 1080p at 30 fps Maximum Resolution
- Intelligent Video System
- PoE Support
- IP66 Ingress Protection and IK10 Vandal Resistance
Compression
Intelligent Features
Abandoned/Missing
Tripwire
Intrusion
Scene Change
Interfaces
|
|
|
|---|---|---|
| WebUI Old | SmartPSS | DSS Express S |
Specifications
